Brushless Gimbal for NEX 5/6/7/550D or GF2
- Thread starter Musky
- Start date
Burntpixel
Member
This looks really good! I have been searching for something that is 2 axis that would support a Panasonic GH2. I have 2 of these cameras and would like to fly(crash) LOL them. They are hacked to shoot north of 150Mbps. Those that have bought this,are you guys using it as a single operator set up? I mean the pilot is also the camera operator. My GH2 with a Olympus 12MM lens/battery weighs in at 590 grams.
I would be putting it on a DJI F550 hopefully.
Thanx
Matt in the ATL
nigelbrogan
Member
The more I read about this gimbal the more interested I get, do any of you have it fitted to a dji s800? I love the versatility of the different cameras that can be used. Some pictures would be great of the rig you have fitted it to.
cscristian
New Member
Hello.First of all thank you that you buy this gimbal.i will try to give you some tip to fit your needs.Because is an small pin incompatibility by Martinez Board with MOS Soft to control tilt there are 2 option...
1.you can swap motors and reverse IMU to right by 90 degree and swap settings in GUI (ROLL settings will be TILT settings and TILT will be ROLL)and you can use A1 Input to control TILT (in normal condition control ROLL)
2.Need solder skill.You can solder a small wire to pin23 (A0) on atmega (that is unconnected) and that is input to control TILT.The ROLL signal will be on pin board A1
That is need to solve the signal problem.
Another user say that not fit 550D because of IMU.To solve that you can put IMU on back of plate in the same position.with a 50mm objective i know is fit but bigger objective i not guarantee....
Another tip is to balance as good as possible your camera (is very easy to adjust because of gimbal construction. First Roll and Then TILT.For TILT use that long screw and look on marks on right and left to be on same level) and play with PID to adjust to your camera.All gimbal have PID for nex5 and i am sure that work most of case.but consider to PLAY with PID and make perfect
I hope soon to make a video to show you how to adjust and to highlight what is nice on this gimbal.
Feel free to ask if you have problems.
1.you can swap motors and reverse IMU to right by 90 degree and swap settings in GUI (ROLL settings will be TILT settings and TILT will be ROLL)and you can use A1 Input to control TILT (in normal condition control ROLL)
2.Need solder skill.You can solder a small wire to pin23 (A0) on atmega (that is unconnected) and that is input to control TILT.The ROLL signal will be on pin board A1
That is need to solve the signal problem.
Another user say that not fit 550D because of IMU.To solve that you can put IMU on back of plate in the same position.with a 50mm objective i know is fit but bigger objective i not guarantee....
Another tip is to balance as good as possible your camera (is very easy to adjust because of gimbal construction. First Roll and Then TILT.For TILT use that long screw and look on marks on right and left to be on same level) and play with PID to adjust to your camera.All gimbal have PID for nex5 and i am sure that work most of case.but consider to PLAY with PID and make perfect
I hope soon to make a video to show you how to adjust and to highlight what is nice on this gimbal.
Feel free to ask if you have problems.
Jem
Member
Hello.First of all thank you that you buy this gimbal.i will try to give you some tip to fit your needs.Because is an small pin incompatibility by Martinez Board with MOS Soft to control tilt there are 2 option...
1.you can swap motors and reverse IMU to right by 90 degree and swap settings in GUI (ROLL settings will be TILT settings and TILT will be ROLL)and you can use A1 Input to control TILT (in normal condition control ROLL)
2.Need solder skill.You can solder a small wire to pin23 (A0) on atmega (that is unconnected) and that is input to control TILT.The ROLL signal will be on pin board A1
That is need to solve the signal problem.
Another user say that not fit 550D because of IMU.To solve that you can put IMU on back of plate in the same position.with a 50mm objective i know is fit but bigger objective i not guarantee....
Another tip is to balance as good as possible your camera (is very easy to adjust because of gimbal construction. First Roll and Then TILT.For TILT use that long screw and look on marks on right and left to be on same level) and play with PID to adjust to your camera.All gimbal have PID for nex5 and i am sure that work most of case.but consider to PLAY with PID and make perfect
I hope soon to make a video to show you how to adjust and to highlight what is nice on this gimbal.
Feel free to ask if you have problems.
are you musky then?
View attachment 11428
The gimbal with the NEX 6. A video to follow as possible.
The gimbal with the NEX 6. A video to follow as possible.
Attachments
SMP
Member
| Raport sumar: | ||
| Numarul trimiterii | CO992534578RO | |
| Denumire serviciu | Colet postal extern | |
| Subunitate postala de expediere | Oficiul Postal Bucuresti 3 | |
| Tara destinatie | QUATAR | |
| Data expedierii | 23.04.2013 | |
| Stare actuala | In prelucrare - BSI Bucuresti Same status as before... Guess it's coming by boat... |
nigelbrogan
Member
I thought the deal was about 5 days for postage?
For those of you that have ordered this gimbal, please post a review for those of us looking into possibly purchasing one (whever you receive it!)
Also question for Musky - Can you tweak this gimbal to carry a Sony CX740 camera (bigger motors?) Please PM me with the relevant details and price.
Also question for Musky - Can you tweak this gimbal to carry a Sony CX740 camera (bigger motors?) Please PM me with the relevant details and price.
