DJI and GR-16 HOTT

[Mihnea de Vries]

Hello,

I start buiding a octocopter, but since i'm a complete newbie, i already got into troubles.

I try to connect DJI Main Controller with Graupner GR-16, but it seems the conenctor i got form DJI kit does not fit in GR-16 because of a little shoulder on the connector.
View attachment 3677
Logic says something is wrong here, like DJI is not compatible with Graupner GR-16.

I may try to cut the shoulder but then i'm not sure about the right position of the cable.

Any advice please?

Thanks



[Aerial Media Pros]

You can cut the little tab off with an xacto knife or razor blade. Then to plug into your graupner, there should be a diagram of the wire layout. Usually +/-/Signal. With The wires coming from your wookong, the ORANGE wire is signal. Just make sure the Signal wire is plugged in to the signal side of your Graupner.



[Mihnea de Vries]

Thanks for the tip! It worked! There was no need to rewire the end going to GR-16, the layout is the same with DJI Wookong side : Signal/+/- or orange/red/brown.
