Since I am using Jeti Duplex EX I have programmed my R10 Rx Channel (7) that handles Wookong 'Atti Mode' to deliver a 1350uS signal on Failsafe. (I worked out the 1350 value by assigning a trim pot to CH7 and twiddling it to get 'Blue Failsafe' on the the Tx page in Wookong Assistant).
When I turn off the Tx I get 'FAILSAFE' in the bottom right of Wookong Assistant. I also get a BLUE on the main LED.
I've checked the Jeti R10 Rx is outputting both possible pulse values correctly (1720 and 1350 uS both work) by connecting it to a JetiBox Profi whilst the Tx is switched off.
Does this confirm it is working OK?
And if so could DJI modify the Assistant software so that we see blue highlighted in the Atti Mode indicator bar :tennis: ? Just like in non-PPM?
And one other thought - surely something as capable as the WOOKONG-M can work out when its lost a signal from a Tx without us having to fiddle with stick uS? Particularly with PPM which must have an Rx protocol that says "I ain't in contact with the Tx"?????
View attachment 6773
When I turn off the Tx I get 'FAILSAFE' in the bottom right of Wookong Assistant. I also get a BLUE on the main LED.
I've checked the Jeti R10 Rx is outputting both possible pulse values correctly (1720 and 1350 uS both work) by connecting it to a JetiBox Profi whilst the Tx is switched off.
Does this confirm it is working OK?
And if so could DJI modify the Assistant software so that we see blue highlighted in the Atti Mode indicator bar :tennis: ? Just like in non-PPM?
And one other thought - surely something as capable as the WOOKONG-M can work out when its lost a signal from a Tx without us having to fiddle with stick uS? Particularly with PPM which must have an Rx protocol that says "I ain't in contact with the Tx"?????
View attachment 6773
