Servo wires...
- Thread starter Gunter
- Start date
On my Jr and Spectrum gear the Orange is Signal, Red Power, and Brown is Negative
Rich
Rich
Emowillcox
Member
Hey Gunter this gonna be a camera gimble for your Wookong?
Gunter
Draganflyer X4
Yes. I connected it all up as per instructions from others, but the servo's aren't turning. I have enabled them in the software and they are getting power from a 5V 3A ubec...is this enough power? (Servo needs 4.8V according to the box) The signal wire is connected to the MC via F1 and F2...see below:
View attachment 1417
Attachments
Hey Gunter... I noticed that you are not running S Bus with your FASST setup. Any thoughts on that. I guess you need to plug the servos into a channel on the receiver to see if they are good.
Rich[
QUOTE=Gunter;13868]Yes. I connected it all up as per instructions from others, but the servo's aren't turning. I have enabled them in the software and they are getting power from a 5V 3A ubec...is this enough power? (Servo needs 4.8V according to the box) The signal wire is connected to the MC via F1 and F2...see below:
View attachment 2390[/QUOTE]
Rich[
QUOTE=Gunter;13868]Yes. I connected it all up as per instructions from others, but the servo's aren't turning. I have enabled them in the software and they are getting power from a 5V 3A ubec...is this enough power? (Servo needs 4.8V according to the box) The signal wire is connected to the MC via F1 and F2...see below:
View attachment 2390[/QUOTE]
Gunter
Draganflyer X4
Rich, I have never used S bus before, being a bit of a newbie to all this RC stuff. I only found out it was possible to use these ports after changing my build from octo to hexa...bugger!
